YS-SP260SZ大克重雙室真空食品包裝機
YS-SP260SZ大克重雙室真空食品包裝機Heavy?duty Dual?chamber Vacuum Food Packaging Machine
特點Features：
1、適用于各種休閑食品、冷凍食品、預制菜、海鮮等大克重真空包裝，防止產品氧化霉變、腐爛及受潮，有效延長儲存或保鮮期限。
Suitable for heavy-duty vacuum packaging of snacks, frozen foods, prepared dishes, seafood and more. It protects products against oxidation, mildew, spoilage and moisture ingress, effectively extending storage and shelf?life.
2、包裝流程全自動，可抽真空（真空度可達到-0.1MPa）?？筛鶕?jù)充填物料的性質選配不同的下料結構。Fully?automatic packaging process with vacuum pumping (vacuum level up to ?0.1MPa).Different feeding structures can be selected according to the nature of the filled materials.
3、整機可靠性好、操作簡單、包裝效率高，大容積，大抽氣量。
High machine reliability, user?friendly operation, high packaging efficiency, large chamber volume and large pumping capacity.
4、采用觸摸屏操作，PLC控制，封口溫度自動補償，控溫精準，封口美觀大方。
It adopts touch screen operation, PLC control, automatic compensation of sealing temperature, precise temperature control, and neat, attractive seals.
5、包裝材料：復合膜，如：純鋁，鍍鋁等預制袋。
Packaging Materials: Composite film, Pre?made pouches (Pure aluminum film, Metallized film, etc.)
技術參數Technical Parameters：
計量范圍：20 - 2000g（視物料特性而定）
Filling Range:(Subject to material properties)
預制袋：長 ( L ) ：180 - 360mm
Pre-made Pouch 寬 ( W ) ：150 - 260mm
包裝速度：5 - 12 bags/min（視物料特性而定）
Packing Speed:(Subject to material properties)
外型尺寸：2200 * 1500 * 1400 mm
Dimension ( L * W * H )
整機重量：700kg
Weight
總 功 率：AC380V / 50 - 60Hz / 4.5kW
Total Power
氣 源：≥0.6 MPa
Air Supply
1、適用于各種休閑食品、冷凍食品、預制菜、海鮮等大克重真空包裝，防止產品氧化霉變、腐爛及受潮，有效延長儲存或保鮮期限。
Suitable for heavy-duty vacuum packaging of snacks, frozen foods, prepared dishes, seafood and more. It protects products against oxidation, mildew, spoilage and moisture ingress, effectively extending storage and shelf?life.
2、包裝流程全自動，可抽真空（真空度可達到-0.1MPa）?？筛鶕?jù)充填物料的性質選配不同的下料結構。Fully?automatic packaging process with vacuum pumping (vacuum level up to ?0.1MPa).Different feeding structures can be selected according to the nature of the filled materials.
3、整機可靠性好、操作簡單、包裝效率高，大容積，大抽氣量。
High machine reliability, user?friendly operation, high packaging efficiency, large chamber volume and large pumping capacity.
4、采用觸摸屏操作，PLC控制，封口溫度自動補償，控溫精準，封口美觀大方。
It adopts touch screen operation, PLC control, automatic compensation of sealing temperature, precise temperature control, and neat, attractive seals.
5、包裝材料：復合膜，如：純鋁，鍍鋁等預制袋。
Packaging Materials： Composite film, Pre?made pouches (Pure aluminum film, Metallized film, etc.)
計量范圍：20 - 2000g（視物料特性而定）
Filling Range:(Subject to material properties)
預制袋：長 ( L ) ：180 - 360mm
Pre-made Pouch 寬 ( W ) ：150 - 260mm
包裝速度：5 - 12 bags/min（視物料特性而定）
Packing Speed:(Subject to material properties)
外型尺寸：2200 * 1500 * 1400 mm
Dimension ( L * W * H )
整機重量：700kg
Weight
總 功 率：AC380V / 50 - 60Hz / 4.5kW
Total Power
氣 源：≥0.6 MPa
